Name: HPMS Sample Sections

Display Field: HPMS_SAMPLE_ID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Within the extent of all Federal-aid eligible roads, a random selection of roadway sections is used to represent various attributes at a system-wide level for the purposes of assessing the performance and condition of the network. This process helps to reduce any burden that may be imposed on the States to perform data collection to meet their HPMS reporting requirements. These sections of the network are referred to as Sample Panel sections. Moreover, the Sample Panel sections are selected randomly and are intended to give a statistically valid representation of the State's road network. Due to the structure of the HPMS data model, the States are not required to extract the Sample Panel data items, as long as the data in their submittal covers the Sample Panel. States are encouraged to submit their entire dataset for each data item. FHWA will dynamically assign values to the Sample Panel sections, using the data provided by the States. This should help to lessen the data processing burden on States that are currently collecting more than the minimum coverage.

Service Item Id: 3631ba14238a446dbb17495be2d4cdba

Copyright Text: Iowa Department of Transportation

Default Visibility: false

MaxRecordCount: 10000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 50000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0761160724169908E7
YMin: 4917983.523783512
XMax: -1.0028466449926231E7
YMax: 5393134.540943814
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [76, 0, 115, 255]
Width: 3
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: true

HasM: true

Time Info:

Start Time Field: EFFECTIVE_START_DATE
End Time Field: EFFECTIVE_END_DATE
Track ID Field: null
Time Extent:
[0182/07/08 00:00:00 UTC, 2051/12/21 00:00:00 UTC]

Time Reference: N/A
Time Interval: 1
Time Interval Units: esriTimeUnitsDays
Has Live Data: false
Export Options:
Use Time: true
Time Data Cumulative: false
Time Offset: -1 (esriTimeUnitsSeconds)

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• EVENT_ID ( type: esriFieldTypeString, alias: EVENT_ID, length: 38 )
• ROUTE_ID ( type: esriFieldTypeString, alias: ROUTE_ID, length: 15 )
• FROM_MEASURE ( type: esriFieldTypeDouble, alias: FROM_MEASURE )
• TO_MEASURE ( type: esriFieldTypeDouble, alias: TO_MEASURE )
• BUSINESS_DATE ( type: esriFieldTypeDate, alias: BUSINESS_DATE, length: 8 )
• EFFECTIVE_START_DATE ( type: esriFieldTypeDate, alias: EFFECTIVE_START_DATE, length: 8 )
• EFFECTIVE_END_DATE ( type: esriFieldTypeDate, alias: EFFECTIVE_END_DATE, length: 8 )
• HPMS_SAMPLE_ID ( type: esriFieldTypeString, alias: HPMS_SAMPLE_ID, length: 12 )
• PEAK_LANES ( type: esriFieldTypeSmallInteger, alias: PEAK_LANES )
• COUNTER_PEAK_LANES ( type: esriFieldTypeSmallInteger, alias: COUNTER_PEAK_LANES )
• TURN_LANES_R ( type: esriFieldTypeSmallInteger, alias: TURN_LANES_R )
• TURN_LANES_L ( type: esriFieldTypeSmallInteger, alias: TURN_LANES_L )
• AADT_SINGLE_UNIT ( type: esriFieldTypeInteger, alias: AADT_SINGLE_UNIT )
• PCT_PEAK_SINGLE ( type: esriFieldTypeDouble, alias: PCT_PEAK_SINGLE )
• AADT_COMBINATION ( type: esriFieldTypeInteger, alias: AADT_COMBINATION )
• PCT_PEAK_COMBINATION ( type: esriFieldTypeDouble, alias: PCT_PEAK_COMBINATION )
• K_FACTOR ( type: esriFieldTypeDouble, alias: K_FACTOR )
• DIR_FACTOR ( type: esriFieldTypeDouble, alias: DIR_FACTOR )
• FUTURE_AADT ( type: esriFieldTypeInteger, alias: FUTURE_AADT )
• PCT_GREEN_TIME ( type: esriFieldTypeDouble, alias: PCT_GREEN_TIME )
• NUMBER_SIGNALS ( type: esriFieldTypeSmallInteger, alias: NUMBER_SIGNALS )
• STOP_SIGNS ( type: esriFieldTypeSmallInteger, alias: STOP_SIGNS )
• AT_GRADE_OTHER ( type: esriFieldTypeSmallInteger, alias: AT_GRADE_OTHER )
• SIGNAL_TYPE ( type: esriFieldTypeInteger, alias: SIGNAL_TYPE )
• LANE_WIDTH ( type: esriFieldTypeSmallInteger, alias: LANE_WIDTH )
• PCT_PASS_SIGHT ( type: esriFieldTypeDouble, alias: PCT_PASS_SIGHT )
• LOCERROR ( type: esriFieldTypeString, alias: LOCERROR, length: 100 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
