Name: National Highway System

Display Field: NATIONAL_HIGHWAY_SYSTEM

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This field indicates the state functional classification of the road segment. NATIONAL HIGHWAY SYSTEM

Service Item Id: 3631ba14238a446dbb17495be2d4cdba

Copyright Text: Iowa Department of Transportation

Default Visibility: false

MaxRecordCount: 10000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 50000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0761100078598566E7
YMin: 4917982.72889024
XMax: -1.0028509860110238E7
YMax: 5391488.734041136
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: NATIONAL_HIGHWAY_SYSTEM
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 3
Default Label: <all other values>
UniqueValueInfos:
• Value: 1
  Label: 1 - NHS
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [181, 63, 85, 255]
  Width: 3
• Value: 2
  Label: 2 - MAJOR AIRPORT NHS CONNECTOR
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [61, 189, 49, 255]
  Width: 3
• Value: 3
  Label: 3 - MAJOR PORT FACILITY NHS CONNECTOR
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [58, 36, 171, 255]
  Width: 3
• Value: 4
  Label: 4 - MAJOR AMTRACK STATION NHS CONNECTOR
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [53, 155, 189, 255]
  Width: 3
• Value: 5
  Label: 5 - MAJOR RAIL/TRUCK TERMINAL NHS CONNECTOR
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [181, 154, 63, 255]
  Width: 3
• Value: 6
  Label: 6 - MAJOR INTER CITY BUS TERMINAL NHS CONNECTOR
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [196, 59, 169, 255]
  Width: 3
• Value: 7
  Label: 7 - MAJOR PUBLIC TRANSPORTATION OR MULTI-MODAL PASSENGER TERMINAL NHS CONNECTOR
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [49, 189, 144, 255]
  Width: 3
• Value: 8
  Label: 8 - MAJOR PIPELINE TERMINAL NHS CONNECTOR
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [58, 82, 156, 255]
  Width: 3
• Value: 9
  Label: 9 - MAJOR FERRY TERMINAL NHS CONNECTOR
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [179, 93, 46, 255]
  Width: 3
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: true

HasM: true

Time Info:

Start Time Field: EFFECTIVE_START_DATE
End Time Field: EFFECTIVE_END_DATE
Track ID Field: null
Time Extent:
[0182/07/08 00:00:00 UTC, 2051/12/21 00:00:00 UTC]

Time Reference: N/A
Time Interval: 1
Time Interval Units: esriTimeUnitsDays
Has Live Data: false
Export Options:
Use Time: true
Time Data Cumulative: false
Time Offset: -1 (esriTimeUnitsSeconds)

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• EVENT_ID ( type: esriFieldTypeString, alias: EVENT_ID, length: 38 )
• ROUTE_ID ( type: esriFieldTypeString, alias: ROUTE_ID, length: 15 )
• FROM_MEASURE ( type: esriFieldTypeDouble, alias: FROM_MEASURE )
• TO_MEASURE ( type: esriFieldTypeDouble, alias: TO_MEASURE )
• BUSINESS_DATE ( type: esriFieldTypeDate, alias: BUSINESS_DATE, length: 8 )
• EFFECTIVE_START_DATE ( type: esriFieldTypeDate, alias: EFFECTIVE_START_DATE, length: 8 )
• EFFECTIVE_END_DATE ( type: esriFieldTypeDate, alias: EFFECTIVE_END_DATE, length: 8 )
• NATIONAL_HIGHWAY_SYSTEM ( type: esriFieldTypeInteger, alias: NATIONAL_HIGHWAY_SYSTEM , Coded Values: [1: 1 - NHS] , [2: 2 - MAJOR AIRPORT NHS CONNECTOR] , [3: 3 - MAJOR PORT FACILITY NHS CONNECTOR] , ...6 more... )
• LOCERROR ( type: esriFieldTypeString, alias: LOCERROR, length: 100 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
